Designing a Rear Extension: How to Balance Light, Space and Planning Rules

A rear extension has one job: to make the back of the house work harder. It also happens to be the project where small decisions carry the most weight — where a sliding door sits, whether the ceiling lifts by 30cm, how much glass faces west. Get those right and you gain a room you use every day. Get them wrong and you gain an expensive corridor.

Two things decide whether the design succeeds: the envelope the planning rules allow you to build, and the way daylight behaves once it is up. Deal with both before you fall in love with an image.

Start with the planning envelope

In England, most rear extensions are covered by permitted development, which means no full planning application — provided you stay inside a set of limits. The important ones for a typical house are these:

• Depth. A single-storey rear extension can project up to 4m from the original rear wall if the house is detached, and 3m if it is semi-detached or terraced. A two-storey extension is limited to 3m for all house types.
• Height. Single-storey extensions are capped at 4m overall. Where the extension comes within 2m of a boundary, the eaves height must not exceed 3m.
• Two-storey conditions. The eaves and ridge should not be higher than the existing roof, the roof pitch should match, and any upper-floor side window must be obscure-glazed and non-opening below 1.7m.
• Materials. They should be similar in appearance to the existing house — brick to brick, slate to slate.
• Coverage. Extensions and other buildings must not cover more than half the land around the original house.
• Exclusions. No balconies, verandas or raised platforms. Flats, listed buildings, and houses in conservation areas or under an Article 4 direction often lose some or all of these rights.

“Original house” means the property as first built, or as it stood on 1 July 1948 — not as you bought it. If a previous owner already extended, that depth counts against your allowance. Scotland, Wales and Northern Ireland have their own versions of these rules, and England also has a neighbour consultation route that can allow larger single-storey extensions — up to 8m for detached houses — subject to prior approval. Because the details vary and local policies change, check your own position with the local planning authority or a planning consultant before drawing anything. A short written confirmation is worth more than an internet forum.

Orientation decides where the glass goes

Walk into the garden at three points in the day and note where the sun lands. A south-facing rear wall gets sun for most of the day and is generous with light, but it is also the hardest to keep cool in a warm summer. West-facing glazing collects low evening sun, which is lovely in April and punishing in July. East gives clean morning light and goes quiet by lunchtime. North light is soft, even and cool — genuinely useful over a kitchen worktop or a desk.

A workable compromise: put the largest openings where you want the view and the connection to the garden, then add shade on the sunny side. An overhang of 600mm to 900mm, a deep reveal, a sliding external screen or a planting trellis all cut summer sun without blocking winter light. Solar control glass is another option, though it changes the colour of the view slightly.

Glazing: how much, and what kind

As a rough working rule, daylight from a vertical window reaches about twice the height of the window head into the room. A 2.1m head gives you useful light around 4m in. Beyond that, you are relying on roof glazing or bouncing light off pale surfaces.

Doors and openings

Sliding doors give the widest uninterrupted glass and suit a wide, shallow extension. Bifolds open the whole wall but need space to stack. A pair of French doors plus a fixed panel is often cheaper and warmer. Whichever you choose, keep the threshold flush and as slim as the frame allows; a 100mm step undoes a lot of the gain.

Roof glazing

A roof lantern throws light deep into the plan and looks good over a dining table. A flat rooflight is cheaper, less obtrusive and easier to seal. Place either where it will light a wall or a floor you actually use, not just the middle of the room. It is also worth remembering that building regulations now deal with overheating as well as insulation, so a wall of south glass with no shading strategy can come back to you as a design problem, not just a comfort one.

Ceiling heights and the feeling of space

Most extensions are built at around 2.4m, because that matches the existing house. Lifting to 2.7m or 3m is often the single cheapest way to make a room feel twice the size, and it costs little extra in structure. Watch the constraints: the underside of a first-floor window cill, the 4m overall height limit, and the depth of the steel beam carrying the new roof, which can eat 250mm or more.

A vaulted ceiling with the structure on show suits a single-storey extension and works well with a rooflight at the ridge. A flat ceiling with a lantern gives a more traditional feel. Pick one idea and commit to it — mixing a vault with a bulky flat-roof lantern rarely resolves well.

Joining old to new

The junction is where extensions show their age. Keep floor levels continuous, use the same flooring through the opening, and make the structural opening generous — a 1.8m-wide opening reads as a doorway, while 3m or more reads as one continuous space. Line up new windows with existing ones where you can, and repeat a material from the old house on the new one.

A sensible order of work

1. Measure the existing house and confirm the permitted development position in writing.
2. Sketch two or three options at the right depth and test them with tape on the floor of the garden.
3. Commission a measured survey and a set of drawings if you need planning or building regulations approval.
4. Get a structural engineer involved early, especially for wide openings and any roof glazing.
5. Deal with party wall notices and drainage runs before the builder starts.
6. Agree a written scope, programme and payment schedule.

The test that matters

Before you settle the design, sit in the proposed room at 8am, at 2pm and at 7pm — or imagine it honestly, standing in the garden. Ask where you will eat breakfast, where the light will fall in February, and how the doors will open when two people and a dog go outside at once. If the answers are easy, the drawings are probably right. And where planning, party wall or structural questions arise, take proper professional advice rather than a guess: it is far cheaper before the foundations go in.
